EN10216-2 P265GH Pipe, EN10216-2 P265GH Pipe, P265GH Pipe, EN10216-2 P265GH Seamless Pipe, EN10216-2 P265GH Pressure Pipe, EN10216-2 P265GH CS Pipe
Manufacturing Carbon Steel Pipe in EN10216-2 P265GH. CS EN10216-2 P265GH Pipe, IBR Approved Dealer, Distributor, Exporter, Supplier in India.
EN 10216-2 P265GH Pipe is a steel with carbon content from about 0.05% up to 2.1% by weight. The definition of carbon steel from the American Iron and Steel Institute (AISI) states: no minimum content is specified or required for Chromium, Cobalt, Molybdenum, Nickel, Niobium, Titanium, Tungsten, Vanadium, Zirconium, or any other element to be added to obtain a desired alloying effect;, the specified minimum for Copper does not exceed 0.40%;, or the maximum content specified for any of the following elements does not exceed the percentages noted: Manganese 1.65%; Silicon 0.60%; Copper 0.60%.
The term EN 10216-2 P265GH Pipe may also be used in reference to steel which is not stainless steel; in this use EN 10216-2 P265GH Pipe may include alloy steels. High carbon steel has many different uses such as milling machines, cutting tools (such as chisels) and high strength wires. These applications require a much finer microstructure, which improves the toughness.
As the Carbon percentage content rises, steel has the ability to become harder and stronger through heat treating; however, it becomes less ductile. Regardless of the heat treatment, a higher carbon content reduces weldability. In carbon steels, the higher carbon content lowers the melting point.
Valour Alloys Inc., Carry a Full Inventory of EN 10216-2 P265GH Pipe for High Temperature and Pressure Services or for General Applications like transporting Oil, Gas, Crude Oil, Water ans Steam.
We Supply EN 10216-2 P265GH Pipe in Grades in Specification ASTM A106 Grade A/B/C, ASTM A333 Grade 6 Pipe, IS3589 Fe330 / Fe410 Pipe, EN 10216-2 P235GH / P265GH, ASTM A500 Structural Pipe Etc. are used in many Application Industries.
Valour Alloys Inc. specializes in EN 10216-2 P265GH Pipe with years of Experience in Manufacturing EN 10216-2 P265GH Pipe. we offer High Quality, at Lower Cost with Best Service in Industry. Our Manufacturing Unit Equiped with the State-of-the-art Machineries. All Our Labour's are Highly Skilled and Trained, work in Safe Environment, we follow Strict Quality Control Norms, we follow Optimum use of Resources with minimum Wastage in Manufacturing Process, Recycle all Wastage. Our well Connected and Strong Network Provide Smooth Logistic Services to our Client's Worldwide.
EN 10216-2 P265GH Seamless Pipe
EN 10216-2 P265GH Seamless Pipe
We Supply Carbon Steel Pipes in ASTM A106 Grade B, ASTM A106 Grade C, ASTM A53 Grade B, ASTM A333 Grade 3, ASTM A333 Grade 6, ASTM A334 Grade 1, ASTM A334 Grade 6, ASTM A179, ASTM A192, ASTM A210 A1, ASTM A210 C. The grade indicates the testing methods required for a given application. It is critical that structural grades of Carbon Steel Pipe not be used for Pressure or Fluid applications.
EN 10216-2 P265GH Welded Pipes Manufacturer, EN 10216-2 P265GH Square Pipes stockist, EN 10216-2 P265GH Polished Pipes, EN 10216-2 P265GH GR. B Round Tubes Exporter
1. Material Composition: P265GH is a non-alloy quality steel grade defined in the EN 10216-2 standard. It is primarily composed of carbon, manganese, silicon, and phosphorus, with trace amounts of sulfur and other elements. The controlled composition ensures its suitability for high-temperature applications.
2. Seamless Construction: EN 10216-2 P265GH pipes are manufactured using a seamless process, which means they are free from any longitudinal or transverse welds. This construction method not only enhances their strength but also ensures a smooth inner surface, reducing friction and resistance in fluid transportation.
3. Elevated Temperature Service: These pipes are specifically designed for use in applications involving elevated temperatures. They are commonly utilized in industries such as power generation, petrochemical, and boiler manufacturing, where the material needs to withstand high heat and pressure conditions.
4. Mechanical Properties: P235GH exhibits good mechanical properties, making it suitable for the intended applications. It has a minimum yield strength of 235 megapascals (MPa) and a minimum tensile strength of 360 to 500 MPa, depending on the wall thickness of the pipe.
5. Versatile Applications: Due to its elevated-temperature capabilities, P235GH pipes find application in a range of industrial processes. They are commonly used in the construction of boilers, heat exchangers, and pressure vessels, where the ability to handle high-pressure steam or hot gases is essential.
6. Compliance with Standards: EN 10216-2 P265GH pipes conform to European standards, ensuring their quality, performance, and safety. They are manufactured in accordance with stringent production and testing requirements, making them reliable for critical applications.
7. Corrosion Resistance: While P265GH is not a corrosion-resistant material like stainless steel, it can be used in environments where corrosion is not a primary concern. Proper maintenance and protective coatings can extend the lifespan of these pipes in less aggressive environments.
Carbon Steel Pipe EN 10216-2 P265GH is a seamless, non-alloy steel pipe designed for elevated temperature service. Its composition, mechanical properties, and compliance with European standards make it a reliable choice for industries where the ability to withstand high temperatures and pressures is crucial. Whether in boiler manufacturing, power generation, or other industrial applications, P235GH plays a vital role in ensuring efficient and safe operations.
EN 10216-2 P265GH Pipe Range
| EN 10216-2 P265GH Pipe Outer Diameter Size | 1/4" NB To 30" NB (Nominal Bore Size) |
| EN 10216-2 P265GH Pipe Wall Thickness | Schedule 20 To Schedule XXS (Heavier On Request) Up to 250 mm Thickness |
| EN 10216-2 P265GH Pipe Length | 5 To 7 Meters, 09 To 13 Meters, Single Random Length, Double Random Length And Customize Size. |
| EN 10216-2 P265GH Pipe Ends | Plain Ends / Beveled Ends / Coupling |
| EN 10216-2 P265GH Pipe Specification | ASME SA/ASTM A106 / ASTM A333 / BS1239 / BS3509 / IS3589 / EN 10216-2 / ASTM A500 Etc. |
| EN 10216-2 P265GH Pipe Grades | ASTM A106 GRADE A / B / C, ASTM A333 GRADE 1 / 3 / 6, IS1239 Light / Medium / Heavy, IS3589 FE330/FE410, EN 10216-2 P235GH / P265GH, ASTM A500 GRADE A / B / C Etc. |
| EN 10216-2 P265GH Pipe Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, API. |
| EN 10216-2 P265GH Pipe Type | Seamless - Hot Rolled / Cold Drawn |
| EN 10216-2 P265GH Pipe Delivery Conditions | As Rolled, Cold Drawn, Normalizing Rolled, Thermomechanical Rolled / Formed, Normalizing Formed, Normalized and Tempered / Quenched and Tempered - BR / N / Q /T |
| EN 10216-2 P265GH Pipe Coating | Epoxy Coating / Colour Paint Coating / 3LPE Coating. |
| EN 10216-2 P265GH Pipe Machinery | Draw Bench / Pilger / De-Coiler / Edge Miller / Welding Line / Heat Treatmen Furnace / Pickling Tank / Cutting Bench etc. |
| EN 10216-2 P265GH Pipe Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment |
| EN 10216-2 P265GH Pipe Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| EN 10216-2 P265GH Pipe Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| EN 10216-2 P265GH Pipe Other Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, PWHT etc. |
| EN 10216-2 P265GH Pipe Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC. |
Chemical Composition of EN 10216-2 P265GH Pipe
| Steel grades | EN10216-2 CHEMICAL COMPOSITION (LADLE ANALYSIS) | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| C% max | Si% max | Mn% max | P% max | S% max | Cr% max | Mo% max | Ni% max | Al.cał% min | Cu% max | Nb% max | Ti% max | V% max | Cr+ Cu+ Mo+ Ni% MAX | |
| P195GH | 0.13 | 0.35 | 0.70 | 0.025 | 0.020 | 0.30 | 0.08 | 0.30 | ≥ 0.020 | 0.30 | 0.010 | 0.040 | 0.02 | 0.70 |
| P235GH | 0.16 | 0.35 | 1,20 | 0.025 | 0.020 | 0.30 | 0.08 | 0.30 | ≥ 0.020 | 0.30 | 0.010 | 0.040 | 0.02 | 0.70 |
| P265GH | 0.20 | 0.40 | 1,40 | 0.025 | 0.020 | 0.30 | 0.08 | 0.30 | ≥ 0.020 | 0.30 | 0.010 | 0.040 | 0.02 | 0.70 |
| 16Mo3 | 0.12- 0.20 | 0.35 | 0.40- 0.70 | 0.025 | 0.020 | 0.30 | 0.25- 0.35 | 0.30 | ≥ 0.020 | 0.30 | - | - | - | - |
| 14MoV6-3 | 0.10- 0.15 | 0.15- 0.35 | 0.40- 0.70 | 0.025 | 0.020 | 0.30- 0.60 | 0.50- 0.70 | 0.30 | ≥ 0.020 | 0.30 | - | 0.22-0.28 | - | - |
| 13CrMo4-5 | 0.15 | 0.50- 1,00 | 0.30- 0.60 | 0.025 | 0.020 | 1,00- 1,50 | 0.45- 0.65 | 0.30 | ≥ 0.020 | 0.30 | - | - | - | - |
| 10CrMo9-10 | 0.10- 0.17 | 0.35 | 0.40- 0.70 | 0.025 | 0.020 | 0.70- 1,15 | 0.40- 0.60 | 0.30 | ≥ 0.020 | 0.30 | - | - | - | - |
Mechanical Properties of EN 10216-2 P265GH Pipe
| EN 10216-2 Mechanical properties | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Steel grades | Mechanical properties during tensile testing in room temperature | Resilience | |||||||||||
| Upper yield limit or yield strength Re or R0.2 for wall thickness of t min | Tensile strength Rm |
Elongation A min% |
Minimum energy average absorbed KVJ at the temperature of 0°C | ||||||||||
| T≤16 | 16<T≤40 | 40<t≤60 | 60<T≤60 | I | T | ||||||||
| MPa | MPa | MPa | MPa | MPa | I | t | 20 | 0 | -10 | 20 | 0 | ||
| P195GH | 195 | - | - | - | 320- 440 | 27 | 25 | - | 40 | 28 | - | 27 | |
| P235GH | 235 | 225 | 215 | - | 360- 500 | 25 | 23 | - | 40 | 28 | - | 27 | |
| P265GH | 265 | 255 | 245 | - | 410- 570 | 23 | 21 | - | 40 | 28 | - | 27 | |
| 16Mo3 | 280 | 270 | 260 | - | 450- 600 | 22 | 20 | 40 | - | - | 27 | - | |
| 14MoV6-3 | 320 | 320 | 310 | - | 460- 610 | 20 | 18 | 40 | - | - | 27 | - | |
| 13CrMo4-5 | 290 | 290 | 280 | - | 440- 590 | 22 | 20 | 40 | - | - | 27 | - | |
| 10CrMo9-10 | 280 | 280 | 270 | - | 480- 630 | 22 | 20 | 40 | - | - | 27 | - | |
Mechanical Properties of EN 10216-2 P265GH Pipe
| Steel Grade | Steel Standard | Steel Grade | Steel Standard | Steel Grade |
|---|---|---|---|---|
| P235GH | DIN 17175 | St 35.8 | ||
| P265GH | DIN 17175 | St 45.8 | ||
| 16Mo3 | DIN 17175 | 15Mo3 | ||
| 10CrMo55 | 15Mo3 | BS 3606 | 621 | |
| 13CrMo45 | DIN 17175 | BS 3606 | 620 | |
| 10CrMo910 | DIN 17175 | 13CrMo44 | BS 3606 | 622 |
| 25CrMo4 | 10CrMo910 | |||
| P355N | DIN 17179 | StE 355 | ||
| P355NH | DIN 17179 | TStE 355 | ||
| P355NL1 | DIN 17179 | WStE 460 | ||
| P460N | DIN 17179 | TStE 460 | ||
| P460NH | DIN 17179 | WStE 460 | ||
| P460NL1 | DIN 17179 | TStE 460 |
Other Available Products of EN 10216-2 P265GH
| EN 10216-2 P265GH Carbon Steel Round Pipe | EN 10216-2 P265GH Carbon Steel Dairy Pipe |
| EN 10216-2 P265GH CS Exhaust Pipe | EN 10216-2 P265GH Carbon Steel Flexible Pipe |
| EN 10216-2 P265GH Carbon Steel Round Pipe | EN 10216-2 P265GH Carbon Steel Rectangular Pipe |
| EN 10216-2 P265GH Carbon Steel Round Pipe | EN 10216-2 P265GH Carbon Steel Schedule 40 Pipe |
| EN 10216-2 P265GH Carbon Steel Sch 10 Pipe | EN 10216-2 P265GH CS Schedule 5 Pipe |
| EN 10216-2 P265GH Carbon Steel Schedule 80 Pipe | EN 10216-2 P265GH CS Threaded Pipe |
| EN 10216-2 P265GH Carbon Steel Seamless Pipe | EN 10216-2 P265GH Carbon Steel Rectangular Pipes |
| EN 10216-2 P265GH Carbon Steel Round Pipes | EN 10216-2 P265GH CS Rectangular Pipe |
| EN 10216-2 P265GH Carbon Steel Rectangular Pipes | EN 10216-2 P265GH CS Structural Carbon Pipe |
EN 10216-2 P265GH Application
- Oil and Gas equipments
- Offshore Technology
- Seawater Desalination Plants
- Chemical Industry
- Airport, Malls, Buildings
- Storage Tanks
- Medical Industry
- Civil Engineering
- Pressure vessels, Reactor tanks, and Heat exchangers
- Rotors, impellers and shafts
- Power Plants
- Petrochemical
- Shipbuilding Industry
- Mining Industry
- Food Equipments Industry
Supplying EN 10216-2 P265GH Pipe to Countries -
We Export EN 10216-2 P265GH Pipe to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen, Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East Etc.
Distributing EN 10216-2 P265GH Pipe to Cities -
We Export EN 10216-2 P265GH Pipe to Navi Mumbai, Indore, Baroda, Muscat, Secunderabad, Gimhae-si, Kanpur, Colombo, Kuala Lumpur, Bhopal, Pimpri-Chinchwad, Rajkot, Haryana, Hanoi, Ernakulam, Chandigarh, Surat, Los Angeles, Hong Kong, Ahmedabad, Perth, Petaling Jaya, Hyderabad, Mumbai, Algiers, Edmonton, Ludhiana, Ho Chi Minh City, Karachi, Bangkok, Dallas, Bengaluru, Jakarta, Granada, Seoul, Cairo, Geoje-si, Rio de Janeiro, Abu Dhabi, Port-of-Spain, Sydney, London, Courbevoie, Vung Tau, Sharjah, Jaipur, Lahore, Chennai, Istanbul, Lagos, Thane, Dubai, Coimbatore, La Victoria, Calgary, Jeddah, Busan, Mexico City, Al Khobar, Caracas, Singapore, Atyrau, Manama, Kolkata, Riyadh, Jamshedpur, Brisbane, Toronto, Noida, Ahvaz, Vadodara, Doha, Visakhapatnam, Ulsan, New Delhi, Gurgaon, Bogota, Howrah, Moscow, Nashik, Ranchi, Nagpur, Al Jubail, Houston, Milan, Chiyoda, Aberdeen, Melbourne, New York, Dammam, Montreal, Santiago, Kuwait City, Pune, Tehran, Thiruvananthapuram, Faridabad, Madrid, Ankara Etc.
