ASTM A358 TP304 EFW Pipe, ASME SA358 Grade 304 Pipe, SS A358 TP304 EFW Pipe, Grade UNS S30400 Pipe, Welded A358 TP304 Pipe, ASTM A358 TP304 Class 1 EFW Pipe, ASTM A358 TP304 Class 2 EFW Pipe.
Manufacturing Stainless Steel ASTM A358 TP304 Pipe. Inox 304 Stainless Steel EFW Pipe, BIS Approved Dealer, Distributor, Exporter, Supplier in India.
ASTM A358 is a standard specification for electric-fusion-welded austenitic chromium-nickel stainless steel pipe suitable for corrosive or high-temperature service. This specification covers a wide range of pipe sizes and wall thicknesses and is commonly used in industries where stainless steel is required for its corrosion resistance and durability.
Valour Alloys Inc., we carry a full inventory of ASTM A358 Stainless Steel Pipe Supply austenitic chromium-nickel stainless steel pipe suitable for corrosive or high-temperature service, or both, or for general applications
We are specializes in ASTM A358 Stainless Steel Pipe with years of Experience in Manufacturing ASTM A358 Stainless Steel Pipe. we offer high quality, lower cost but the best service. As a result to that our ASTM A358 Stainless Steel Pipe export account today is in various countries like Iran, Iraq, Kuwait, Saudi Arabia, Oman, UAE, Singapore, Malaysia, Indonesia, South korea, Chile, Peru, Venezuela, Australia, Nigeria, Angola, Senegal, Mozambique, Algeria, Libya, Azerbaijan, Netherlands, Brazil, Norway, United Kingdom, Mexico, Canada etc.

ASTM A358 Stainless Steel Pipe Manufacturer

ASTM A358 Stainless Steel Pipe Exporter
We Supply Stainless Steel EFW Pipes in Grades in Specification ASME SA / ASTM A269, A312, A213 and Grades 202, 304, 304L, 304H, 304LN, 309s, 310s, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, 254 SMO , 6MO , 6 MOLY, UNS S31254 etc. The grade indicates the testing methods required for a given application.
1. Purpose and Scope:
ASTM A358 sets the standards for the manufacture of electric-fusion-welded stainless steel pipes.
It primarily covers pipes made from austenitic stainless steel grades such as 304, 304L, 316, 316L, 321, and others.
2. Manufacturing Process:
These pipes are typically manufactured by the electric-fusion-welding process, which involves the joining of two or more stainless steel pieces using heat generated by an electric arc.
The molten metal fuses to form a single continuous pipe.
3. Grades of Stainless Steel:
ASTM A358 encompasses various grades of stainless steel known for their corrosion resistance, making them suitable for a wide range of applications, including chemical processing, oil and gas, and more.
4. Dimensions and Sizes:
The standard specifies a range of pipe sizes, from NPS 8 (Nominal Pipe Size) and above.
It also outlines various wall thicknesses to accommodate different pressure requirements.
5. Types of Pipes:
ASTM A358 covers various types of pipes, such as straight-seam or spiral-seam pipes, depending on the manufacturing process used.
6. Testing and Inspection:
The standard specifies requirements for mechanical and chemical properties of the pipes.
It outlines testing methods, including hydrostatic testing, nondestructive electric tests, and more, to ensure the quality and integrity of the pipes.
7. Compliance:
Manufacturers, distributors, and users of stainless steel pipes often refer to ASTM A358 to ensure that their products meet industry standards and regulatory requirements.
ASTM A358 Stainless Steel Pipe is a widely recognized standard that governs the manufacturing and quality requirements for electric-fusion-welded stainless steel pipes. These pipes are known for their durability and resistance to corrosion, making them a vital component in various industries where these qualities are crucial for the safe and reliable transport of fluids and gases.
ASTM A358 Stainless Steel Pipe Range
ASTM A358 Stainless Steel Pipe Outer Diameter Size | Seamless - 1/2" NB TO 18" NB Welded / ERW- 1" NB TO 16" NB EFW - 8" NB TO 110" NB |
ASTM A358 Stainless Steel Pipe Wall Thickness | Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness) |
ASTM A358 Stainless Steel Pipe Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size. |
ASTM A358 Stainless Steel Pipe Ends | Plain Ends / Beveled Ends |
ASTM A358 Stainless Steel Pipe Specification | ASTM A269, ASTM A213, ASTM A312, ASME SA269, ASME SA213, ASME SA312 |
ASTM A358 Stainless Steel Pipe Grades | 202, 304, 304L, 304H, 304LN, 309S, 310S, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, SMO 254, ALLOY 254, 6MO, 6MOLY, UNS S31254 ETC. |
ASTM A358 Stainless Steel Pipe Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, DIN, EN Series. |
ASTM A358 Stainless Steel Pipe Type | Seamless / Welded / ERW / EFW / Square / Rectangular / Cold Draw / Hot Finish / Cold Finish / Coil |
ASTM A358 Stainless Steel Pipe Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw |
ASTM A358 Stainless Steel Pipe Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated, Matt, Mirror |
ASTM A358 Stainless Steel Pipe Machinery | Draw Bench / Pilger / De-Coiler / Edge Miller / Welding Line / Heat Treatmen Furnace / Pickling Tank / Cutting Bench etc. |
ASTM A358 Stainless Steel Pipe Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
ASTM A358 Stainless Steel Pipe Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
ASTM A358 Stainless Steel Pipe Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
ASTM A358 Stainless Steel Pipe Other Testing | Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiographic Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc |
ASTM A358 Stainless Steel Pipe Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS Etc. |
Chemical Composition of ASTM A358 Stainless Steel Pipe
A358 GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
---|---|---|---|---|---|---|---|---|---|---|---|---|
ASTM A358 TP304 | S3040 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-11.0 | ||||
A358 Stainless Steel TP304L | S30403 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-13.0 | ||||
A358 Stainless Steel TP304H | S30409 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-11.0 | ||||
A358 Stainless Steel TP304N | S30451 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-18.0 | 0.10-0.16 | |||
A358 Stainless Steel TP304LN | S30453 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-12.0 | 0.10-0.16 | |||
A358 Stainless Steel TP309S | S30908 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 22.0-24.0 | 12.0-15.0 | 0.75 | |||
A358 Stainless Steel TP309H | S30909 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 22.0-24.0 | 12.0-15.0 | ||||
A358 Stainless Steel TP309Cb | S30940 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 22.0-24.0 | 12.0-16.0 | 0.75 | 10xC min 1.10 max | ||
A358 Stainless Steel TP309HCb | S30941 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 22.0-24.0 | 12.0-16.0 | 0.75 | 10xC min 1.10 max | ||
A358 Stainless Steel TP310S | S3108 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 24.0-26.0 | 19.0-22.0 | 0.75 | |||
A358 Stainless Steel TP310H | S3109 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 24.0-26.0 | 19.0-22.0 | ||||
A358 Stainless Steel TP310Cb | S31040 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 24.0-26.0 | 19.0-22.0 | 0.75 | 10xC min 1.10 max | ||
A358 Stainless Steel TP310HCb | S31041 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 24.0-26.0 | 19.0-22.0 | 0.75 | 10xC min 1.10 max | ||
A358 Stainless Steel TP316 | S3160 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
A358 Stainless Steel TP316L | S31603 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |||
A358 Stainless Steel TP316H | S31609 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
A358 Stainless Steel TP316Ti | S31635 | 0.08 | 2.0 | 0.045 | 0.030 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 5x (C-N) -0.70 | 0.10 | |
A358 Stainless Steel TP316N | S31651 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 0.10-0.16 | ||
A358 Stainless Steel TP316LN | S31653 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | 0.10-0.16 | ||
A358 Stainless Steel TP317 | S3170 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 10.0-14.0 | 3.0-4.0 | |||
A358 Stainless Steel TP317L | S31703 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 | |||
A358 Stainless Steel TP321 | S3210 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-12.0 | 0.10 | |||
A358 Stainless Steel TP321H | S32109 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-12.0 | 0.10 | |||
A358 Stainless Steel TP347 | S3470 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 | ||||
A358 Stainless Steel TP347H | S34709 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 | ||||
A358 Stainless Steel TP347LN | S34751 | 0.05-0.02 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 | 0.20- 50.0 | 0.06-0.10 | ||
A358 Stainless Steel TP348 | S3480 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 | ||||
A358 Stainless Steel TP348H | S34809 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 |
Mechanical Properties of ASTM A358 Stainless Steel Pipe
Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
º F(º C) | |||||
ASTM A358 TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
ASTM A358 TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
ASTM A358 TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
ASTM A358 TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
Equivalent Grade of ASTM A358 Stainless Steel Pipe
ASTM STANDARD | UNS NO. | KOREA/JAPANES | GERMAN | BRITISH | FRENCH | ITALIAN | ||||||||||
KS/JIS Symbol | KS/JIS Numbe | DIN Type | DIN Number | Materiral Number | Remarks | B.S Number | B.S Grade | Remarks | AFNOR Type | NF Number | Ramarks | UNI Type | UNI Number | Ramarks | ||
A 358 Electric-Fusion Welded Austenitic Cr-Ni Alloy sreel Pipe for High-Temperature Service | ||||||||||||||||
Grade 304 | S30400 | STS 304TPY/SUS310STPY | D3588 / G3468 | X5 CrNi 18 9 | 17440 | 1.4301 | (3b) | 3605 | 304S25 | LWHT(3b) | Z6 CN 18.09 | A36-209 | (3b) | X6 CrNi 18 10 | 8317 | (3b) |
Grade 310 | S31000 | STS 310STPY/SUS310STPY | D3588 / G3468 | X 12 CrNi 25 21 | 1.4845 | WBL-470(3b) | (3) | A36-209 | X22 CrNi 25 20 | 6900 | (3b)(11) | |||||
Grade 316 | S31600 | STS 316TPY / SUS316TPY | D3588 / G3468 | X5 CrNiMo 18 10 | 17440 | 1.4401 | (3b) | 3605 | 316S26 | LWHT(3b) | Z6 CND 17.11 | A36-209 | (3b) | X6CrNiMo 17 12 | 8317 | (3b) |
Grade 321 | S32100 | STS 321TPY/ SUS 321TPY | D3588 / G3468 | X10 CrNiTi 18 9 | 17440 | 1.4541 | (3b)(17) | 3605 | 321S22 | LWHT(3b) | Z6 CNT 18.10 | A36-209 | (3b) | X6 CrNiTi 18 10 | 8317 | (3b) |
Grade 347 | S34700 | STS 347TPY/ SUS 347TPY | D3588 / G3468 | X10 CrNiNb 18 9 | 17440 | 1.4550 | (3b)(17) | 3605 | 347S17 | LWHT(3b) | Z6 CN Nb 18.10 | A36-209 | (3b) | X6 CrNiNb 18 10 | 8317 | (3b)#nps |
Other Available Products of ASTM A358 Stainless Steel Pipe
ASTM A358 TP304 Stainless Steel Pipe | ASTM A358 Electric-Fusion-Welded Austenitic Stainless teel Pipe |
ASTM A358 UNS S31254 stainless steel pipe | ASTM A358 TP316L Pipe |
ASTM A358 Stainless Steel Welded Electropolished Pipe | ASTM A358 Class 1 EFW Pipe |
ASTM A358 gr 304 cl1 Stainless Steel Pipe | ASTM A358 Gr. 316l Pipe |
ASTM A358 gr. 316l cl1 Pipe | ASTM A358 Stainless Steel Pipe |
ASTM A358 Stainless Steel Exhaust Pipe | ASTM A358 Class 5 Stainless Steel Pipe |
ASTM A358 Color Coated Pipe | ASTM A358 Grade 316L Pipe |
ASTM A358 Hot Rolled SS Pipes | ASTM A358 Grade 312 class 2 Pipe |
ASTM A358 Stainless Steel Welded Pipe | ASTM A358 TP312 Stainless steel Pipe |
ASTM A358 TP321H Stainless Steel Pipe | Welded stainless steel Pipe ASTM A358 |
ASTM A358 grade 304 class 1 Pipe | ASTM A358 Schedule 40 SS Pipes |
ASTM A358 grade 321 class 1 pipe | ASTM A358 Schedule 80 SS Pipes |
ASTM A358 Welded pipe Supplier | ASTM A358 Class 2 stainless steel efw pipe |
ASTM A358 TP304L Stainless Steel Pipe | ASTM A358 Class 3 EFW Pipe |
ASTM A358 Welded Stainless Steel Pipe | ASTM A358 Grade 304 Class 1 Pipe |
ASTM A358 Stainless Steel Oval Pipe | ASTM A358 Schedule 10 SS Pipes |
ASTM A358 pipe | ASTM A358 Sch 5 Stainless Steel Pipe |
ASTM A358 Stainless Steel Slot Round pipe | ASTM A358 Stainless Steel Electropolished Pipes |
INOX ASTM A358 pipe Supplier | ASTM A358 Stainless Steel Welded Pipe |
ASTM A358 Welded pipes Supplier | ASTM A358 EFW Pipe |
ASTM A358 / ASME SA 358 Pipe | ASTM A358 Stainless Steel EFW Pipe |
ASTM A358 Bright Annealed Pipe | ASTM A358 gr tp316l Pipe |
ASTM A358 CL2 Pipe | ASTM A358 gr. 304l EFW Pipe Exporter |
ASTM A358 CL1 Pipe | ASME SA358 Stainless Steel Pipe |
ASTM A358 Stainless Steel Pipe Application
- Oil and Gas equipments
- Offshore Technology
- Seawater Desalination Plants
- Chemical Industry
- Airport, Malls, Buildings
- Storage Tanks
- Medical Industry
- Civil Engineering
- Pressure vessels, Reactor tanks, and Heat exchangers
- Rotors, impellers and shafts
- Power Plants
- Petrochemical
- Shipbuilding Industry
- Mining Industry
- Food Equipments Industry
Test Certificates
We ASTM A358 Stainless Steel Pipe with the following details Mill Test Certificate according to EN 10204 3.1, PMI Test, Test Report from NABL Approved Lab, 3.2 Certification by External Testing Authority third, ultrasonic test report, and X-ray report.
Quality Assurance
At ASTM A358 Stainless Steel Pipe all types of Such as SS 202 EFW (Fabricated) Pipes, SS 304 EFW (Fabricated) Pipes, SS 304L EFW (Fabricated) Pipes, SS 304H EFW (Fabricated) Pipes, SS 309M EFW (Fabricated) Pipes, SS 309H EFW (Fabricated) Pipes, SS 310S EFW (Fabricated) Pipes, SS 316 EFW (Fabricated) Pipes from raw material purchase to production and product shipping. They are visually inspected for compliance with ASTM, ASME, DIN, EN and JIS codes and standards. We can also designate certified official testing agencies upon customer request so that they can witness the product's material, size and quality compliance reports.
Marking & Packing
Our ASTM A358 Stainless Steel Pipe is packaged to ensure no damage during transit. In the case of export, the standard export packing is in a wooden box. All ASTM A358 Stainless Steel Pipe are marked with our grade, batch number, size and mark. We can also do custom branding on our products as per buyer's unique requirements
Supplying ASTM A358 Stainless Steel Pipe to Countries -
We Export ASTM A358 Stainless Steel Pipe to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen, Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East Etc.
Distributing ASTM A358 Stainless Steel Pipe to Cities -
We Export ASTM A358 Stainless Steel Pipe to Navi Mumbai, Indore, Baroda, Muscat, Secunderabad, Gimhae-si, Kanpur, Colombo, Kuala Lumpur, Bhopal, Pimpri-Chinchwad, Rajkot, Haryana, Hanoi, Ernakulam, Chandigarh, Surat, Los Angeles, Hong Kong, Ahmedabad, Perth, Petaling Jaya, Hyderabad, Mumbai, Algiers, Edmonton, Ludhiana, Ho Chi Minh City, Karachi, Bangkok, Dallas, Bengaluru, Jakarta, Granada, Seoul, Cairo, Geoje-si, Rio de Janeiro, Abu Dhabi, Port-of-Spain, Sydney, London, Courbevoie, Vung Tau, Sharjah, Jaipur, Lahore, Chennai, Istanbul, Lagos, Thane, Dubai, Coimbatore, La Victoria, Calgary, Jeddah, Busan, Mexico City, Al Khobar, Caracas, Singapore, Atyrau, Manama, Kolkata, Riyadh, Jamshedpur, Brisbane, Toronto, Noida, Ahvaz, Vadodara, Doha, Visakhapatnam, Ulsan, New Delhi, Gurgaon, Bogota, Howrah, Moscow, Nashik, Ranchi, Nagpur, Al Jubail, Houston, Milan, Chiyoda, Aberdeen, Melbourne, New York, Dammam, Montreal, Santiago, Kuwait City, Pune, Tehran, Thiruvananthapuram, Faridabad, Madrid, Ankara Etc.
