Stainless steel 317L tube is a type of stainless steel tubing that is made from an austenitic stainless steel alloy. It is made from iron, chromium, nickel, molybdenum, manganese, silicon, phosphorous, carbon, and sulfur SA 213 TP 317L Seamless Tube supplier
Lowering the content of carbon in the production of grade SS 317l Welded Tubing is what ensures that the alloy does not become prone to intergranular corrosion, which in turn stems from the UNS S31700 Round Tubing being used at elevated temperatures, especially in the chromium carbide precipitation range
Stainless Steel 317L is a high-performance, austenitic stainless steel known for its exceptional resistance to corrosion, making it a popular choice for a wide range of industrial applications. Quality 317L Stainless Steel Tube stand out through a combination of verified certifications, precise chemical and mechanical properties, and clear visual and physical attributes.
Valour Alloy specializes in Stainless Steel 317L Tube with years of Experience in Manufacturing Stainless Steel 317L Tube. we offer high quality, lower cost but the best service. As a result to that our Stainless Steel 317L Tube export account today is in various countries like Iran, Iraq, Kuwait, Saudi Arabia, Oman, UAE, Singapore, Malaysia, Indonesia, South korea, Chile, Peru, Venezuela, Australia, Nigeria, Angola, Senegal, Mozambique, Algeria, Libya, Azerbaijan, Netherlands, Brazil, Norway, United Kingdom, Mexico, Canada etc.
Stainless Steel 3167L Seamless Tube
Stainless Steel 3167L Welded Tubes
We Supply Stainless Steel 304 Tube s in Grades in Specification ASME SA /ASTM A269, A312, A213 and Grades 202, 304, 304L, 304H, 304LN, 309s, 310s, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, 254 SMO ,6MO ,6 MOLY, UNS S31254 etc. The grade indicates the testing methods required for a given application.
Easy Ways to Identify Quality Stainless Steel 317L Tubes
Valour Alloys Inc. explain here the top 3 Easy Ways to Identify Quality Stainless Steel 317L Tubes. Before purchase product, we have to Verify Certification and Documentation for genuine material such as Mill Test Reports one of the most important reports to prove a genuine product all Reputable suppliers will provide detailed MTRs or certificates (e.g., ASTM A312, ASTM A213, EN10216-5) that verify the chemical makeup and mechanical properties. If suppliers do not provide the Mil test reports so that time we have to conduct the Chemical Composition and Mechanical Properties Testing.
- Mill Test Reports
- Chemical Composition
- Mechanical Properties
When we talk about Chemical Composition so that time we have to check all the Standard Compositions like Carbon: , Chromium: 18.0–20.0%, Nickel: 11.0–15.0%, Molybdenum: 3.0–4.0% Additional elements like manganese, silicon, phosphorous, and sulfur are present in controlled amounts. Chemical composition its depends on the product and material. For Mechanical Properties, its depends on Tensile and Yield Strength and Hardness Testing, Look for a minimum tensile strength of about 515 MPa and a yield strength of around 205 MPa. A quality tube should also exhibit an elongation of at least 35%, indicating good ductility.
Understanding the Importance of Quality in Stainless Steel 317L Tubes
Do you know why Quality Stainless Steel 317L Tubes are important for industrial applications? because when the engineering industry purchases an SS 317L tube that time they get many advantages from Quality in Stainless Steel 317L Tubes such as Long-Term Durability High-quality 317L tubes maintain their corrosion resistance over time, even under cyclic or extreme service conditions. This means less maintenance, and fewer replacements that is why the quality of products is very important in industrial applications. The quality of SS 317L tube comes with Risk Mitigation also when multiple industries like petrochemical processing, marine, and high-temperature power generation, even minor deviations in material quality can lead to catastrophic failures. High-quality 317L tubes help mitigate risks by providing proven performance under harsh operating conditions.
Understanding the Benefits of Stainless Steel 317L Tube in Industrial Applications
The Stainless Steel 317L Tube comes with multiple benefits for Industrial Applications when we talk about the cost advantage SS 317L tube is popular for the cost advantage Stainless Steel 317L may be higher than some other materials, but its long-term benefits make it a cost-effective choice and if you want to replace and repair it takes less time and ultimately saving money over the lifecycle of the product. When we compare Stainless Steel 317L Tube with other products like Stainless Steel 316L Tube it's similar to each other both products are used in the same industries but they come with different grades. This comparative analysis highlights the importance of selecting the right material for specific industrial applications.
Stainless Steel 317L tube Range
| SS 317L Tubes Outer Diameter Size | Seamless Tube - 6 MM OD TO 114.3 MM OD WELDED / ERW- 10 MM TO 114.3 MM OD |
| SS 317L Tubes Wall Thickness | 0.8 MM TO 4 MM WALL THICKNESS |
| SS 317L Tubes Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size. |
| SS 317L Tubes Ends | Plain Ends / Beveled En |
| SS 317L Tubes Specification | ASTM A-249, A-268, A-269, A-270, A-554, A-688, A-778, DIN 17455, DIN 17456, 17457, DIN 17458 [Class 1] & Its equivalent ASME, DIN & EN Standard. |
| SS 317L Tubes Grades | 202, 304, 304L, 304H, 304LN, 309S, 310S, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, SMO 254, ALLOY 254, 6MO, 6MOLY, UNS S31254 ETC. |
| SS 317L Tubes Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
| SS 317L Tubes Type | Seamless Tube / Steel Welded / ERW / EFW / COLD DRAW / HOT FINISH / COLD FINISH |
| SS 317L Tubes Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw |
| SS 317L Tubes Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
| SS 317L Tubes Machinery | Draw Bench / Pilger / De-Coiler / Edge Miller / Welding Line / Heat Treatmen Furnace / Pickling Tank / Cutting Bench etc. |
| SS 317L Tubes Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
| SS 317L Tubes Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| SS 317L Tubes Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| SS 317L Tubes Other Testing | Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiographic Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc. |
| SS 317L Tubes Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC. |
Chemical Composition of Stainless Steel 317L Tubes
| Element | Content (%) |
| Iron, Fe | Balance |
| Chromium, Cr | 18-20 |
| Nickel, Ni | 11-15 |
| Molybdenum, Mo | 3-4 |
| Manganese, Mn | 2 |
| Silicon, Si | 1 |
| Phosphorous, P | 0.045 |
| Carbon, C | 0.03 |
| Sulfur, S | 0.03 |
Mechanical Properties of Stainless Steel 317L Tubes
| Properties | Metric | Imperial |
| Tensile strength | 595 MPa | 86300 psi |
| Yield strength | 260 MPa | 37700 psi |
| Modulus of elasticity | 200 GPa | 29000 ksi |
| Poisson's ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (in 50 mm) | 55% | 55% |
| Hardness, Rockwell B | 85 | 85 |
Equivalent Grade of Stainless Steel 317L Tubes
| AISI 317L | ASTM A167 | ASTM A182 | ASTM A213 | ASTM A240 |
| ASTM A249 | ASTM A312 | ASTM A774 | ASTM A778 | ASTM A813 |
| ASTM A814 | DIN 1.4438 | QQ S763 | ASME SA240 | SAE 30317L |
Other Available Products Of Stainless Steel 317L Tubes
| Stainless Steel TP 317L Seamless Tube | A249 SS TP 317L Steel Welded Tubes Suppliers |
| ASTM A213 317L Stainless Steel Rectangular Tubes | TP 317L Stainless Steel ERW Tubes Distributors |
| UNS S31703 Stainless Steel Coiled Seamless Tube | Top Quality Stainless Steel TP 317L Heat Ex-changer Tubes |
| Stainless Steel DIN DIN 1.4438 Round Tubing Exporter | TP 317L SS EFW Tubing Stockiest in India |
| Stainless Steel JIS SUS 317L Cold Rolled Coiled Tubing | ASTM A269 317L Stainless Steel Tubing |
| SS 317L Austenitic Stainless Steel Pipes & Tubes | ASTM A213 Stainless Steel TP 317L Capillary Tube |
| Stainless Steel 317L U Shaped Tubing Stockholder | TP 317L Stainless Steel Hydraulic Tubes Suppliers |
| Stainless Steel ASTM A213 TP 317L Welded Tubing | AISI Stainless Steel ASTM A213 317L Seamless Tubing |
| SS ASME SA 249 TP 317L Steel Welded Tubes Exporter | TP 317L Stainless Steel Instrumentation Tubes Exporter |
| ASTM A358 317L Stainless Steel ERW Tubes Manufacturer | Stainless Steel TP 317L Seamless Tube Supplier |
Key Features:
- Corrosion Resistance: Stainless Steel 317L offers outstanding resistance to both general and localized corrosion, including pitting and crevice corrosion. This makes it an ideal choice for applications exposed to aggressive chemical environments.
- High Temperature Performance: Its ability to maintain its mechanical properties at elevated temperatures (up to 1600°F or 870°C) makes it suitable for high-temperature applications like heat exchangers and furnace components.
- Formability: 317L is readily formable and weldable, allowing for various manufacturing processes such as bending, welding, and machining to create custom tube configurations.
- Strength: It maintains good tensile and yield strength even in high-temperature conditions, ensuring structural integrity under demanding circumstances.
- Hygienic Properties: Due to its corrosion resistance and ease of cleaning, Stainless Steel 317L tubes are commonly used in the food and pharmaceutical industries for the transport of sensitive materials.
Test Certificates
We Stainless Steel 317L Tube with the following details Mill Test Certificate according to EN 10204 3.1, PMI Test, Test Report from NABL Approved Lab, 3.2 Certification by External Testing Authority third, ultrasonic test report, and X-ray report.
